Key Features

  • TITO: Issuance / redemption of tickets
  • Cashless: cash to card / card to cash
  • Biometrics: cash to fingerprint / fingerprint to cash
  • Sports betting: payout wins via barcode
  • Money changer
  • Bank card, contactless

Main Unit

  • Security cabinet in steel blue / white aluminium
  • 10“ or 21“ touchscreen display
  • Banknote dispenser Fujitsu F53
    with 2 to 5 cassettes
    Capacity approx. 500 notes per cassette
    (max. of 2,500 banknotes total)
    Payout note by note (spray dispensing)
  • RFID card reader for service functions
  • Banknote validator
    JCM UBA Pro / Cash box 400/900 notes
    JCM iPRO / Cash box 400/900 notes


    • Maximum of 4 coin hoppers
      2 coin hoppers have an extension (for up to 5,000+ coins together)
      2 additional hoppers are possible (a standard and a small one)
    • Note recycler instead of note validator JCM iPRO-RC, JCM UBA Pro-RQ
    • Coin acceptance via coin validator or coin bulk feeder (for up to 250 coins at once)


    • RFID card reader for service functions
      e.g. staff accounts: deposit and withdrawal
      Player card compatibility
    • ITHAKA Epic 950 TITO ticket printer or receipt printer
      TITO tickets, receipts, statistics print outs
      Change of paper via front access
    • Barcode /QR-Code scanner possible
    • Prepared for integration of a bank card payment device /
      PIN Pad


    Modern PC and Software Technology

    • Modern industrial PC
      Reliable fanless Linux PC with SSD
      Uninterruptible Power Supply (UPS)
    • NOVO Cash X-Software concept
      Service interface for a wide range of settings
      Documentation of all operations
      Extensive statistics
      Simple and ergonomic cashier interface
      Status and function messages by e-mail
      Internet connection and thus remote enquiry, remote
      maintenance, remote update possible
      Extensive analysis options for technicians
    • Integration in most Casino Management Systems possible


        • Cabinet and front door made out of 3 mm sheet steel
        • Front door with enhanced 8-point locking mechanism
        • Locking lever with double-bit lock and additional lock cover
        • Double-locking system (4-eye principle)
        • High resistance against break-in


        • Blue LED design edge around the front door
        • Front panel in blue
        • optional: coloured front design NOVOLINE or individual front design according to customer requirements

        Technical Data

        • Cabinet: 59 cm x 179 cm x 59 cm (W x H x D)
        • Base plate: 57 cm x 62 cm (W x D)
        • Weight: 250 kg (depending on configuration)
        • Power Supply: 110-230V
